?LINEAR電池備用IC

發布時間：2023-01-04 16:38:57 瀏覽：1401

ADI提供多方面用作管控電源的備用電池管理器IC，為了實現微控制器系統中的電源監控和電池操控性能提供了完善的單芯片解決方案。LINEAR電池備用IC包括微控制器復位、備用電池轉換、監控定時器、CMOSRAM異步復位和電源故障警示。

應用：

?關鍵微控制器管控

?控制模塊

?智能儀器儀表

?汽車系統

?便攜式儀表設備

LINEAR公司是模擬電路領域歷史悠久的國際品牌，LINEAR電源的μModule芯片式電源模塊產品，廣泛應用于工業與軍工市場。LINEAR于2016年被ADI收購。

ADI公司的隔離μModule?轉換器是完整的系統化封裝(SiP)電源管理解決方案，LINEAR電源在緊湊型表貼BGA封裝內集成DC/DC控制器、功率晶體管、輸入和輸出電容、補償組件以及725 VDC隔離變壓器。LINEAR電源的1.5 W輸出隔離反激式μModule轉換器可有效滿足面對時間和空間限制難題的工程師需要，為全球客戶提供高效、可靠的電源管理解決方案。

深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。

詳情了解LINEAR電源模塊請點擊：http://m.nfda.cn/brand/19.html

1 (23).png

產品型號	Reset Voltage	Isupply (typ)
		A
LT8228		214μ
LT8708		3.9m
LT8708-1		3.9m
LTC4091		10n
LTC4040		570μ
MAX16021	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	5μ
MAX16016	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	5μ
MAX16024	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	8μ
LTC4110
MAX16020	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	5μ
MAX16033	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16034	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16035	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16036	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16037	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16039	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX16040	1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX8672
MAX791	3.3 to 5.5	150μ
MAX6362H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6362L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6362P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6366H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6366L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6366P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX691A	4.5 to 5.0	100μ
MAX693A	4.0 to 4.5	100μ
MAX800	3.3 to 5.5	100μ
MAX6365H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6365L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6365P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6367H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6367L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6367P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6368H	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX6368L	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX6368P	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX6361H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6361L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6361P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6363H	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6363L	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6363P	2.5 to 3.3, 3.3 to 5.5	50μ
MAX6364L	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX6364P	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	50μ
MAX690	4.5 to 5.0	5m
MAX690A	4.5 to 5.0	350μ
MAX690R	2.5 to 3.0	50μ
MAX690S	2.5 to 3.0	50μ
MAX690T	3.0 to 3.5	50μ
MAX691	4.5 to 5.0	5m
MAX692	4.0 to 4.5	5m
MAX692A	4.0 to 4.5	350μ
MAX693	4.0 to 4.5	5m
MAX694	4.5 to 5.0	5m
MAX695	4.5 to 5.0	5m
MAX703	3.3 to 5.5	350μ
MAX704	2.5 to 3.3, 3.3 to 5.5	350μ
MAX704R	2.5 to 3.0	50μ
MAX704S	2.5 to 3.0	50μ
MAX704T	3.0 to 3.5	50μ
MAX802L	4.5 to 5.0	350μ
MAX802R	2.5 to 3.0	50μ
MAX802S	2.5 to 3.0	50μ
MAX802T	3.0 to 3.5	50μ
MAX805L	4.5 to 5.0	350μ
MAX806	2.5 to 3.3	50μ
MAX801	4.0 to 4.5, 4.5 to 5.0	110μ
MAX808	4.0 to 4.5, 4.5 to 5.0	90μ
MAX793	2.5 to 3.3	60μ
MAX794	1.2 to 1.8, 1.8 to 2.5, 2.5 to 3.3, 3.3 to 5.5	60μ
MAX795	2.5 to 3.3	50μ
MAX817	3.3 to 5.5	60μ
MAX818	3.3 to 5.5	45μ
MAX819	3.3 to 5.5	45μ
MAX807	4.0 to 4.5, 4.5 to 5.0	110μ
MAX696	1.2 to 1.8	4m
